1-829264-5 - TE Connectivity
TE Connectivity
1-829264-5
1-0829264-5
1-0829264-5
PCB-Connectors
AMPMODU Mod II V
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- PCB Connector Assembly Type:PCB Mount Receptacle
- Row-to-Row Spacing:2.54mm[.1in]
- Sealable:No
- Connector & Contact Terminates To:Printed Circuit Board
- Series:AMPMODU, HV-100
- Profile:Standard
- Boss:No
- Product Type:Connector
Configuration Features
- Stackable:No
- PCB Mount Orientation:Vertical
- Number of Positions:15
- Number of Rows:2
Contact Features
- Contact Base Material:Copper Alloy
- PCB Contact Termination Area Plating Material:Tin
- Contact Mating Area Plating Material:Gold
- Contact Mating Area Plating Thickness(µin):30
- Contact Type:Socket
- PCB Contact Termination Area Plating Thickness(µm):3
Termination Features
- Termination Method to Printed Circuit Board:Through Hole - Solder
- Termination Post Length:3.1mm[.122in]
Mechanical Attachment
- PCB Mount Retention:Without
Housing Features
- Centerline (Pitch):2.54mm[.1in]
- Housing Color:Green
- Housing Material:Polyester - GF
- Housing Entry Style:Bottom or Top, Closed Entry
Dimensions
- PCB Thickness (Recommended)(mm):1.6
- Height:6.2mm[.244in]
- Tail Length(mm):3.05
Operation/Application
- Pick and Place Cover:Without
Industry Standards
- UL Flammability Rating:UL 94V-0
- MIL-C-55032:No
Packaging Features
- Packaging Method:Carton
- Packaging Quantity:48
Accessories
Accessories
No details available.
