1310851-1 - TE Connectivity
TE Connectivity
1310851-1
0-1310851-1
0-1310851-1
Other Connectors
CONNT, SMB, PCB, SOCKET
B65N07G999X
B65N07G999X
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- RF Interface:SMB
- RF Connector Style:Jack
- Connector System:Cable-to-Board
- Sealable:No
- Connector & Contact Terminates To:Printed Circuit Board
Configuration Features
- Port Configuration:Single Port
- Number of Positions:1
- PCB Mount Orientation:Vertical
- Number of Coaxial Contacts:1
Electrical Characteristics
- Impedance(O):50
Body Features
- Body Material:Brass
- Body Plating Material:Gold
Contact Features
- RF Connector Center Contact Plating Material:Gold
- RF Connector Center Contact Material:Brass
- Connector Product Type:Connector Assembly
Termination Features
- Termination Method to Printed Circuit Board:Through Hole
Mechanical Attachment
- RF Connector Coupling Mechanism:Snap-On
- Connector Mounting Type:Board Mount
- RF Contact Captivation Method:Mechanical
- Detent:Without
Dimensions
- RF Connector Mated Outer Diameter (Approximate):4.75mm[.187in]
- Height Above PC Board:7.59mm[.298in]
- PCB Tail Length:3.64mm[.143in]
Usage Conditions
- Operating Temperature Range:-55 – 155°C[-67 – 311°F]
Packaging Features
- Packaging Method:Carton
Other
- Dielectric Material:PTFE
- Additional Features:Board Standoff, Pin Protection
- Grade:Commercial
Accessories
Accessories
No details available.
