1544222-2 - TE Connectivity
TE Connectivity
1544222-2
0-1544222-2
0-1544222-2
Other Connectors
Relay Connector / Miscellaneo
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- Product Type:Leadframe
Configuration Features
- Solder Inlay:Without
- Winding Direction:Down
Body Features
- Clip Style:Single-In-Line (SIL)
- Hold-Down Feature:Without
- Clip Length:1.4mm[.055in]
- Frame Thickness:.25mm[.01in]
- Clip Type:Y1
- Frame Width:18.1mm[.712in]
Contact Features
- Contact Base Material:Phosphor Bronze
- Contact Plating Material:Tin
- Pin Length:9.5mm[.374in]
Termination Features
- Contact Termination Type:Through Hole
Housing Features
- Centerline (Pitch)(in):.1
- Centerline(mm):2.54
Dimensions
- PCB Thickness (Accepted):.63mm[.025in]
- Standoff Height:.55mm[.022in]
- Gap Size:.52mm[.02in]
Packaging Features
- Packaging Quantity:40000
Accessories
Accessories
No details available.
