163301-6 - TE Connectivity
TE Connectivity
163301-6
0-0163301-6
0-0163301-6
Rectangular connectors
Mate-N-Lok Kontaktstift
Ø 2,13 mm, messing, Bandware
Ø 2,13 mm, messing, Bandware
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- Product Type:Contact
- Connector System:Wire-to-Wire
- Connector & Contact Terminates To:Wire & Cable
Contact Features
- Contact Type:Pin
- Contact Base Material:Brass
- Contact Mating Area Plating Material:Pre-Tin
- Contact Termination Area Plating Material:Pre-Tin
- Wire Contact Termination Area Plating Material:Pre-Tin
- Contact Angle:Straight
Termination Features
- Wire/Cable Size(AWG):20 – 17
- Wire/Cable Size(mm²):.5 – 1
- Termination Type:Crimp
Mechanical Attachment
- Connector Mounting Type:Cable Mount
- Contact Retention in Housing:With
- Wire Insulation Support:Without
- Contact Retention Type within Housing:Locking Lance
Dimensions
- Mating Pin Diameter:2.1mm[.082in]
- Accepts Wire Insulation Diameter Range:1.8 – 3.3mm[.071 – .13in]
Operation/Application
- Circuit Application:Power
- For Multiple Crimp:No
Industry Standards
- Glow Wire Rating:Standard Part - Not Glow Wire
- VDE Tested:No
Packaging Features
- Packaging Method:Reel
- Packaging Quantity:4500
Other
- For Use With:Pin (Cap) Housing
- Wire Type:Stranded
- Wire/Cable Type:Discrete Wire
Accessories
Accessories
No details available.
