1934222-1 - TE Connectivity
TE Connectivity
1934222-1
0-1934222-1
0-1934222-1
Other Connectors
Z-PACK TinMan Backplane Conne
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- Connector System:Board-to-Board
- Row-to-Row Spacing:1.4mm[.055in]
- Connector Style:Receptacle
- Shrouded:Unshrouded
- Sealable:No
- Connector & Contact Terminates To:Printed Circuit Board
- Connector Type:Connector Assembly
- Signal Arrangement:Differential
- Product Type:Connector
- Make First / Break Last:No
Configuration Features
- Number of Signal Positions:64
- Stackable:No
- Number of Pairs:32
- Number of Positions:96
- Number of Rows:12
- Number of Columns:8
- Board-to-Board Configuration:Co-Planar, Right Angle
- PCB Mount Orientation:Right Angle
- Pairs per Column:4
Electrical Characteristics
- Impedance(O):100
- UL Voltage Rating(VAC):250
- Operating Voltage(VAC):250
Signal Characteristics
- Data Rate(Gb/s):10
- Number of Differential Pairs per Column:4
- Differential Impedance(O):100
Body Features
- Shield Material:Phosphor Bronze
Contact Features
- Contact Base Material:Phosphor Bronze
- Contact Current Rating (Max)(A):.5
- PCB Contact Termination Area Plating Material Finish:Matte
- Contact Termination Area Plating Material:Tin
- Contact Design:Dual Beam
- Contact Mating Area Plating Material:Gold
- Contact Style:Press-Fit
- PCB Contact Termination Area Plating Thickness:.5µm[20µin]
- Contact Transmits (Typical):Signal (Data)
- Contact Type:Socket
Termination Features
- Termination Method to Printed Circuit Board:Through Hole - Press-Fit
Mechanical Attachment
- PCB Mount Retention Type:Action/Compliant Tail
- PCB Mount Retention:With
- Guide Hardware:Without
- PCB Mount Alignment:Without
- Mating Alignment:With
- Mating Alignment Type:Guide Slot
- Connector Mounting Type:Board Mount
- Mating Retention:Without
Housing Features
- Centerline (Pitch):1.9mm[.075in]
- End Wall Location:None
- Housing Color:Black
- Housing Material:LCP (Liquid Crystal Polymer)
Dimensions
- PCB Hole Diameter(mm):.47
- PCB Thickness (Recommended):1.57mm[.062in]
- Length(mm):15.35
- Tail Length:2.2mm[.087in]
- Height(mm):20.2
- Width(mm):21.61
Usage Conditions
- Operating Temperature Range:-65 – 90°C[-85 – 194°F]
Operation/Application
- Circuit Application:Signal
- For Use With:Header Assembly
Industry Standards
- Agency/Standard:UL
- UL Rating:Recognized
- UL File Number:E28476
- UL Flammability Rating:UL 94V-0
Packaging Features
- Packaging Method:Box & Tube, Tube
