201182-4 TE Connectivity
201182-4 - TE Connectivity
TE Connectivity
201182-4
0-0201182-4
Other Connectors
STRAIN RELIEF CLAMP


Technical Characteristics

Technical Characteristics

Product Type Features

  • Thread Size:8-32
  • Product Type:Hardware
  • Strain Relief:With

Body Features

  • Strain Relief Type:Short
  • Cable Exit Angle:180°, 90°
  • Material:Carbon Steel

Mechanical Attachment

  • Mounting Hardware:U Bolt, Wire Guide, Protection Sleeve and Nut
  • Hardware Type:Strain Relief Clamp
  • Mounting Bracket Material:Carbon Steel
  • Mounting Bracket Plating Material:Nickel

Dimensions

  • Cable Opening Diameter:28.58 x 13.97mm[1.125 x .55in]
  • Width:23.32mm[.918in]
  • Length:43.26mm[1.703in]
  • Height:65.1mm[2.563in]

Operation/Application

  • For Use With:42-Position Mixed Connectors, 50-Position Standard Connectors

Packaging Features

  • Packaging Method:Bag
  • Packaging Quantity:1

Other

  • Comment:Hardware supplied unassembled.

Accessories

Accessories

No details available.
