2103245-1 - TE Connectivity
TE Connectivity
2103245-1
0-2103245-1
0-2103245-1
Other Connectors
HEMS Connectors & Battery Sol
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- Connector Style:Housing for female terminals
- Connector System:Wire-to-Board, Wire-to-Device, Wire-to-Wire
- Sealable:Yes
- Hybrid Connector:No
- Primary Locking Feature:On the Terminal
- Strain Relief:No
Configuration Features
- Number of Positions:2
- Number of Rows:1
Electrical Characteristics
- Nominal Voltage Architecture(V):12, 24, 42, 48, 80, 90, 125, 240, 500, 550, 600
- Operating Voltage(VDC):600
Body Features
- Color:Orange
- Cable Exit Angle:180°
- Body Material:PA GF
Contact Features
- Mating Tab Width:2.8mm[.11in]
Mechanical Attachment
- Mounting Feature:Without
- Terminal Position Assurance:No
- Polarized:Yes
Housing Features
- Centerline (Pitch):10.4mm[.409in]
Dimensions
- Width:32.4mm[1.2756in]
- Height:12.6mm[.496in]
- Length:22.4mm[.8819in]
Usage Conditions
- Operating Temperature Range:-40 – 125°C[-40 – 257°F]
Operation/Application
- Circuit Application:Signal
Industry Standards
- Degree of Protection:IP6K9K
- UL Flammability Rating:UL 94-HB
Other
- Connector Position Assurance Capable:No
- Serviceable:No
Accessories
Accessories
No details available.
