3-829073-5 - TE Connectivity
TE Connectivity
3-829073-5
3-0829073-5
3-0829073-5
PCB-Connectors
AMPMODU Breakaway
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- PCB Connector Assembly Type:PCB Mount Header
- Connector & Contact Terminates To:Printed Circuit Board
- Series:AMPMODU
- Product Type:Connector
Configuration Features
- Stackable:Yes
- PCB Mount Orientation:Vertical
- Number of Positions:35
- Number of Rows:1
Electrical Characteristics
- Insulation Resistance(MO):5000
Body Features
- Post Size:.63mm[.0248in]
Contact Features
- Contact Base Material:CuZn
- PCB Contact Termination Area Plating Material:Tin
- Contact Shape:Square
- Contact Mating Area Plating Material:Gold Flash
- Contact Type:Pin
- Contact Current Rating (Max)(A):5
Termination Features
- Termination Method to Printed Circuit Board:Through Hole
- Termination Post Length:3mm[.118in]
Mechanical Attachment
- PCB Mount Retention:Without
Housing Features
- Centerline (Pitch):2.54mm[.1in]
- Housing Color:Green
- Housing Material:PBTP GF
Dimensions
- Stack Height:12.3mm[.484in]
- Mating Post Length:6mm[.236in]
Usage Conditions
- Operating Temperature Range(°C):-65 – 125
Accessories
Accessories
No details available.
