328588-0 - TE Connectivity
TE Connectivity
328588-0
0-0328588-0
0-0328588-0
Contacts and Splices
SOLISTRAND Terminals & Splice
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- Product Type:Splice
- Sealable:No
- Splice Type:Butt Splice
- Serrated:Yes
- Accessory Type:Splice
- Barrel Type:Closed Barrel
- Wire/Cable Type:Copper
- Insulated:No
- Support Style:Non - Insulation Support
- Discrete Wire Type:Solid
Configuration Features
- Number of Serrations:8
Body Features
- Splice Features:Strap
- Splice Material:Copper
- Plating Material:Gold
- Plating Thickness(µin):50
Contact Features
- Terminal & Splice Style:Splice
- Contact Plating Thickness:1.27µm[50µin]
- Contact Plating Material:Gold
Mechanical Attachment
- Wire Insulation Support:Without
Dimensions
- Wire Size(AWG):24 – 20
- Wire Size(mm²):.2 – .6
- Barrel Inside Diameter:1.09mm[.043in]
- Wire Size(CMA):320 – 1290
- Material Thickness:.51mm[.02in]
- Overall Length:12.44mm[.49in]
- Inside Diameter (Recovered):1.092mm[.043in]
- Outside Diameter:2.667mm[.105in]
Usage Conditions
- Operating Temperature Range:170°C[338°F]
Operation/Application
- Heavy Duty:No
Industry Standards
- Government Qualified:No
Packaging Features
- Packaging Method:Loose Piece
- Packaging Quantity:1000
Other
- Military Category:No
Accessories
Accessories
No details available.
