360010-1 - TE Connectivity
TE Connectivity
360010-1
0-0360010-1
0-0360010-1
Contacts and Splices
FASTON Terminals - Premier &
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- Housing Type:Receptacle Housing
- Sealable:No
- Insulated:No
- Style Code:C
- Product Type:Terminal Housing
Configuration Features
- Number of Positions:3
Body Features
- Housing Color:Natural
- Mating Retention:Without
- Mating Alignment:With
Contact Features
- Terminal & Splice Style:Receptacle
- Terminal Orientation:Straight
Mechanical Attachment
- Mounting Style:Free Hanging
Housing Features
- Housing Material:Nylon 6/6
Dimensions
- Centerline:6.35mm[.25in]
- Length:35.69mm[1.41in]
Usage Conditions
- Operating Temperature Range:-40 – 105°C[-40 – 221°F]
Industry Standards
- UL Flammability Rating:UL 94V-0
Packaging Features
- Packaging Method:Package
- Packaging Quantity:1
Accessories
Accessories
No details available.
