5-102694-2 - TE Connectivity
TE Connectivity
5-102694-2
5-0102694-2
5-0102694-2
PCB-Connectors
AMPMODU MT
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- Connector & Contact Terminates To:Wire & Cable
- Row-to-Row Spacing:2.54mm[.1in]
- Product Type:Connector
- Connector Style:Receptacle
- Strain Relief:Without
- Wire/Cable Type:Discrete Wire
- Applied Pressure:High
Configuration Features
- Number of Positions:8
- Number of Rows:2
- Stamped:Yes
- Backwall/Post Interruptions:Without
Electrical Characteristics
- Termination Resistance:15 mO
- Insulation Resistance:5000 MO
- Dielectric Withstanding Voltage:600 V
Contact Features
- Contact Base Material:Copper Alloy
- Contact Shape:Square
- Wire Contact Termination Area Plating Material:Tin
- Contact Mating Area Plating Material:Gold
- Contact Mating Area Plating Thickness:.762µm[30µin]
- Contact Type:Socket
- Contact Current Rating (Max)(A):3
- Wire Contact Termination Area Plating Thickness:1.27 – 2.54µm[50 – 100µin]
Termination Features
- Termination Method to Wire & Cable:Insulation Displacement Crimp (IDC)
Mechanical Attachment
- Panel Mount Feature:Without
- Mating Connector Lock:Without
- Contact Retention Type:Locking Lance
- Mating Retention:With
- Mating Alignment:Without
- Mating Retention Type:Polarized Lock
- Mating Alignment Type:Polarization
- Contact Retention:With
Housing Features
- Centerline (Pitch):2.54mm[.1in]
- Housing Color:Black
- Housing Material:PBT
Dimensions
- Insulation Diameter:1.27mm[.05in]
- Height:15.24mm[.6in]
- Length:10.16mm[.4in]
- Wire/Cable Size(AWG):26 – 22
- Wire/Cable Size(mm²):.12 – .4
- Wire/Cable Size(CMA):252.8 – 642.4
Usage Conditions
- Operating Temperature Range(°C):-65 – 105
Operation/Application
- Pick and Place Cover:Without
- For Use With:Socket Housing
Industry Standards
- Approved Standards:CSA LR7189, UL E28476
- UL Flammability Rating:UL 94V-0
Packaging Features
- Packaging Method:Tray
- Packaging Quantity:310
Accessories
Accessories
No details available.
