6-1761615-5
6-1761615-5
Other Connectors
Step-Z Products
0
75



Technical Characteristics

Technical Characteristics

Product Type Features

  • PCB Connector Assembly Type:PCB Mount Receptacle
  • Connector System:Board-to-Board
  • Row-to-Row Spacing:2mm[.0786in]
  • Sealable:No
  • Connector & Contact Terminates To:Printed Circuit Board
  • Product Type:Connector
  • Boss:No

Configuration Features

  • Stackable:Yes
  • PCB Mount Orientation:Vertical
  • Number of Positions:200
  • Board-to-Board Configuration:Mezzanine
  • Number of Rows:18

Electrical Characteristics

  • Insulation Resistance(MO):18
  • Dielectric Withstanding Voltage(VAC):500
  • Voltage(VAC):48

Body Features

  • Busbar Mating Area Plating Thickness:500

Contact Features

  • Contact Base Material:Copper Alloy
  • PCB Contact Termination Area Plating Material:Tin-Silver
  • Contact Configuration:Dual Beam, Single Beam
  • Contact Mating Area Plating Material:Gold
  • Contact Mating Area Plating Thickness:.76µm[29.9212µin]
  • Contact Type:Socket
  • Contact Current Rating (Max)(A):1
  • Contact Plating Thickness:Gold:30 - Nickel:50
  • Contact Layout:Matrix

Termination Features

  • Termination Method to Printed Circuit Board:Through Hole - Solder

Mechanical Attachment

  • Mating Alignment:With
  • Mating Alignment Type:Polarization
  • PCB Mount Retention:Without
  • PCB Mount Alignment:Without
  • Connector Mounting Type:Board Mount

Housing Features

  • Centerline (Pitch):1.3mm[.051in]
  • Housing Material:Thermoplastic

Dimensions

  • Stack Height(mm):25, 27, 28, 30, 35, 40
  • Stack Height(in):1.575
  • PCB Thickness (Recommended)(in):.76
  • Height:20.65mm[.811545in]

Usage Conditions

  • Operating Temperature Range:0 – 100°C[32 – 212°F]

Operation/Application

  • Assembly Process Feature:None
  • Pick and Place Cover:With
  • Circuit Application:Signal
  • For Use With:Plug Assembly

Packaging Features

  • Packaging Method:Tray
  • Packaging Quantity:25

Accessories

Accessories

No details available.
