Product Description
Chassis or PC Board Mountable Power Line Filters for Emission Control. Designed to bring most digital equipment (including those with switching power supplies) into compliance with FCC Part 15J, Class B conducted emission limits
Product Type Features
- Filtered:Yes
- Filter Type:Power Line
- Input Type:PCB Pins .065" Diagonal
- Output Type:PCB Pins .065" Diagonal
- Ground Choke Option:No
Electrical Characteristics
- Current Rating(A):6
- Leakage Current (Max) (120VAC, 60Hz)(mA):.3
- Leakage Current (Max) (250VAC, 50Hz)(mA):.5
- Voltage (Max)(VAC):250
Mechanical Attachment
- Mount Style:Printed Circuit Board
Usage Conditions
- Operating Temperature Range(°C):-10 – 40
Other
- Comment:450kHz to 30MHz
