696018-1
0-0696018-1
0-0696018-1
Contacts and Splices
Terminal|509-1,900 CMA
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- Terminates To:Wire & Cable
- FASTON:Yes
- Disconnect Type:Quick Disconnect Pin
- Insertion Force:Low
- Insulated:Yes
- Discrete Wire Type:Stranded
- Wire Stop:Yes
Electrical Characteristics
- Voltage (Max)(V):300
Body Features
- Fully Insulated:No
- Plating Material:Tin
Contact Features
- Terminal Orientation:Straight
- Crimp Type:F-Crimp
Mechanical Attachment
- Wire Insulation Support:With
- Mating Retention Type:Dimple
Dimensions
- Wire Size(CMA):509 – 1900
- Mating Tab Width:5.21mm[.205in]
- Mating Tab Thickness:.51mm[.02in]
- Receptacle Stock Thickness:.41mm[.016in]
- Wire Insulation Diameter (Max):3.43mm[.135in]
- Overall Length:20.32mm[.8in]
Usage Conditions
- Operating Temperature Range(°C):105
Packaging Features
- Packaging Method:Loose Piece
- Packaging Quantity:1000
Other
- Barrel Color:Red
Accessories
Accessories
No details available.
