926521-2 - TE Connectivity
TE Connectivity
926521-2
0-0926521-2
0-0926521-2
Contacts and Splices
Positive Lock
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- Connector System:Wire-to-Board, Wire-to-Wire
- Terminates To:Wire/Cable
- Housing Type:Receptacle Housing
- Sealable:No
- Insulated:No
- Product Type:Terminal Housing
Configuration Features
- Number of Positions:2
Body Features
- Housing Color:Black
- Mating Retention:Without
- Mating Alignment:With
Contact Features
- Terminal & Splice Style:Receptacle
- Terminal Orientation:Straight
Mechanical Attachment
- Mounting Style:Free Hanging
- Mating Alignment Type:Polarization
Housing Features
- Housing Material:Polyamide 6.6
Dimensions
- Centerline:10mm[.393in]
Usage Conditions
- Operating Temperature Range:-40 – 105°C[-40 – 221°F]
Industry Standards
- UL Flammability Rating:UL 94V-2
Packaging Features
- Packaging Method:Carton
- Packaging Quantity:1300
Accessories
Accessories
No details available.
