927841-2 - TE Connectivity
TE Connectivity
927841-2
0-0927841-2
0-0927841-2
Rectangular connectors
MNL Stift 3,5 mm
AWG 22-18,messing, Bandware
AWG 22-18,messing, Bandware
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- Product Type:Contact
- Connector System:Wire-to-Wire
- Connector & Contact Terminates To:Wire & Cable
Electrical Characteristics
- Operating Voltage(VAC):250
Contact Features
- Contact Current Rating (Max)(A):17
- Contact Type:Pin
- Contact Base Material:Phosphor Bronze
- Contact Mating Area Plating Material:Pre-Tin
- Contact Termination Area Plating Material:Pre-Tin
- Wire Contact Termination Area Plating Material:Pre-Tin
- Contact Angle:Straight
Termination Features
- Wire/Cable Size(AWG):20 – 17
- Wire/Cable Size(mm²):.52 – 1.04
- Termination Type:Crimp
Mechanical Attachment
- Connector Mounting Type:Cable Mount
- Contact Retention in Housing:With
- Wire Insulation Support:With
- Contact Retention Type within Housing:Locking Lance
Dimensions
- Mating Pin Diameter:3.56mm[.14in]
- Accepts Wire Insulation Diameter Range:1.4 – 2.3mm[.055 – .09in]
Usage Conditions
- Operating Temperature Range:-55 – 105°C[-67 – 221°F]
Operation/Application
- Circuit Application:Power
- For Multiple Crimp:No
Industry Standards
- Glow Wire Rating:Standard Part - Not Glow Wire
Packaging Features
- Packaging Method:Carton
- Packaging Quantity:2500
Other
- Wire/Cable Type:Discrete Wire
Accessories
Accessories
No details available.
