HFD16 - Series

• 5A switching capability
• UL insulation system: Class F available
• Plastic sealed and flux proofed types available
• Standard PCB layout
• Product in accordance to IEC 60335-1 available
• Environmental friendly product (RoHS compliant)
• Outline Dimensions: (15.7 x 10.6 x 11.8) mm

• Contact Arrangement? 1Z
• Contact Resistance: AgNi, AgSnO2
• Contact Rating: 3A 30VDC 1A 125VAC
• Max. switching Voltage: 250VAC / 220VDC
• Max. Switching Power: 250VA / 90W
• Mechanical Endurance: 1×10^7OPS
• Electrical Endurance: 1×10^5OPS( NO:AgNi?85°C?1s on 9s off, 3A 30VDC) 1×10^4OPS(NO: AgNi?85°C?1s on 9s off, 5A 125VAC)

• Insulation Resistance: 1000M? (500VDC)
• Dielectric Strength: 1100VAC 1min
• Operate Time (max): 5ms
• Release Time (max): 5ms
• Ambient Temperature: -40°C ~ 85°C
• Terminal Type: THT

• Nominal Voltage: (2.4~24)VDC (2.4~24)VDC
• Coil Power: H type: 200mW; S type: 360mW; Nil: 450mW;
